MAX. SWING ..................... 26.77"
SWING OVER CARRIAGE ............ 16.54"
MAX. MACHINING LENGTH .......... 60.672
BAR WORK CAPACITY .............. 4.0"
X-AXIS TRAVEL .................. 8.875"
Z-AXIS TRAVEL .................. 63.625"
CHUCK SIZE ..................... 15"
SPINDLE SPEED .................. 3300 RPM
SPINDLE NOSE ................... A2-11
SPINDLE BORE ................... 4.41"
TURRET TYPE .................... 12 POSITION DRUM TYPE
NUMBER OF TOOLS ................ 12
TURNING TOOL SHANK ............. 1"
BORING BAR SHANK DIAMETER ...... 1-1/2"
TAILSTOCK STROKE ............... 62.375"
TAILSTOCK TAPER ................ MT#5
MAIN SPINDLE MOTOR ............. 40/30HP
APPROX. WEIGHT ................. 17,000 LBS.
EQUIPPED WITH:
- MAZATROL NEXUS MATRIX CONTROL
- TOOLEYE
- 15" 3-JAW HYDRAULIC CHUCK
- 12 POSITION TURRET
- TAILSTOCK
- CHIP CONVEYOR
- ALL AVAILABLE TOOLHOLDERS AND MANUALS
Inspect Under Power in our NJ Warehouse. We will Prep and Load for you.
This equipment has been sold. Similar equipment available now is shown below.
