Used 2023 SMART NL6000 XL | LATHES, COMBINATION, N/C & CNC

Sell Your SMART NL6000 XL
516-922-7977
sales@primemach.com
ConditionUsed
1 available
Sell Your SMART NL6000 XL

Document (1)

NL4000_5000_6000-En210407_web.pdf

Overview

Type:
LATHES, COMBINATION, N/C & CNC
Manufacturer:
SMART
Model:
NL6000 XL
Year:
2023
Stock #:
69290
Status:
For Sale

Description

SMART NL6000 XL, 2023, 40.55" swing, 37.8" max cutting diameter, 128" machining length, 73 hp, 1,200 RPM, 24" hydraulic chuck, chip conveyor. Features 12 turret stations. Two machines available.

Swing40.55"1,030 mm
Swing Over Cross Slide3.46"87.884 mm
Max Cutting Dameter37.8"960.12 mm
Machining Length128"3,251.2 mm
# Axis22
X-Axis Travel18.71"475.23 mm
Z-Axis Travel129.92"3,300 mm
Chuck Size24"609.6 mm
Bar Capacity6.52"165.61 mm
Power73 hp54.4 kW
Max RPM1,200 RPM1,200 RPM
TailstockYesYes
Live ToolingNoNo
Spindle Bore7.125"180.97 mm
Spindle Nosea1-15a1-15
Sub SpindleNoNo
Rapid Traverse Rate X-Axis630 ipm
Rapid Traverse Rate Z-Axis394 ipm
# Turret Stations12 station12 station
ControlCNC (Fanuc Oi-TF Plus)CNC (Fanuc Oi-TF Plus)
Dimensions280" X 105"280" X 105"
Weight44,00044,000

24" 3-Jaw Hydraulic Chuck
Manual Steady Rest
Chip conveyor
Tool Presetter

Two Like New machines Available
