| Spindle Size | 6" | 152.4 mm |
| X-Horiz Tvl of Table | 160" | 4,064 mm |
| Y-Vert Tvl of Head | 120" | 3,048 mm |
| Power | 50 hp | 37.3 kW |
| RPM | 2,500 RPM | 2,500 RPM |
| Table-W | 86" | 2,184.4 mm |
| Table-L | 70" | 1,778 mm |
| Spindle Tvl. | 27.6" | 701.04 mm |
| Control | CNC (TOSNUC 999) | CNC (TOSNUC 999) |
Travels:
X-Axis Travel (Cross Movement of Table) 160"
Y-Axis Travel (Vertical Movement of Head) 120"
Z-Axis Travel (Longitudinal of Column)60"
W-Axis Travel (Spindle Extension) 28"
Table:
Table Working Surface 70.8" x 86.6"
Table Loading Capacity 44,000 Lbs
B-Axis Table Indexing 0.0001 Degree
Toshiba Tosnuc 999 CNC Control Permits Quick Switiching Between Manual, MDI an Automatic
Operation Modes
60 Position Tool Changer
Renishaw RMP60 Part Probe
Chip Conveyor
2-Speed Geared headstock
44,000 Lb table Capacity
Glass Scale Feedback
Coolant Thu Spindle
Cat 50 Taper
Angle Plates
Inspect Under Power - used for High Precision Mold Work
