MAZAK QTN-350MSY CNC TURNING CENTER W/BARFEEDER - NEW: 2009
$79,500.00 USD
ConditionUsed
1 available
MAZAK QTN-350MSY CNC Turning Center, 2009, with bar feeder. Features: 29.5" swing over bed, Y-axis, live milling, and sub spindle. Equipped with MAZATROL MATRIX NEXUS control, high-pressure coolant, tool presetter, chip conveyor.
SPECIFICATIONS:
SWING OVER BED 29.5"
MAX CUTTING DIAMETER 14.75"
MAX CUTTING LENGTH 25.6"
X-AXIS TRAVEL 11.75"
Y-AXIS Yes
Y-AXIS TRAVEL 4" (+/- 2")
Z-AXIS TRAVEL 26.25"
CHUCK SIZE 15"
BAR CAPACITY 4"
SPINDLE BORE 4.4"
SPINDLE NOSE A2-11
SPINDLE MOTOR 30 hp
SPINDLE SPEED 3,300 RPM
SUB SPINDLE Yes
SUB SPINDLE - CHUCK SIZE 10"
SUB SPINDLE - SPINDLE NOSE A2-8
SUB SPINDLE - SPINDLE MOTOR 20 hp
SUB SPINDLE - SPINDLE SPEED 4,000 RPM
TURRET CAPACITY 12
LIVE MILLING Yes
LIVE MILLING SPEED 4,000 RPM
MAZATROL MATRIX NEXUS CONTROL (VOICE ADVISER)
LNS QUICK LOAD SERVO S3 MAGAZINE BAR FEEDER (5’)
Y-AXIS
LIVE MILLING
SUB SPINDLE
HAINBUCH COLLET CHUCK (MAIN)
15”, 3-JAW ATS (400-128) HYDRAULIC CHUCK (MAIN)
10” 3-JAW KITAGAWA (B-210) HYDRAULIC CHUCK (SUB)
MAZAK SUPERFLOW T8-1000 HIGH-PRESSURE COOLANT SYSTEM (1,000 PSI)
TOOL PRESETTER
PARTS CATCHER
CHIP CONVEYOR
PARTS CONVEYOR
(7) LIVE TOOL HOLDERS
SEE PHOTOS FOR FULL LIST OF MAZATROL CONTROL OPTIONS
** AS OF APRIL 2025, CUTTING TIME – 9,616 HOURS
** FULL REPLACEMENT COST, AS EQUIPPED - $350,000+
** MACHINE CUT PRIMARILY ALUMINUM & CARBON STEEL
** IN PLANT, UNDER POWER, AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
** FULL LIST OF MAZATROL CONTROL OPTIONS SHOWN IN PHOTOS
** MIST COLLECTOR SHOWN IN PHOTOS IS NOT INCLUDED WITH THE MACHINE
** ALL TOOL HOLDERS SHOWN IN THE TURRET WILL GO WITH THE MACHINE (NOT THE INSERTS)
