DISTANCE BETWEEN CENTERS..................... 39"
SWING OVER BED............................... 16.92"
SWING OVER CROSS SLIDE....................... 7.87"
CROSS SLIDE (X) TRAVEL....................... 8.66"
BED WIDTH.................................... 12.00"
BED HEIGHT................................... 13.77"
SPINDLE NOSE................................. A2-5 ASA
HOLE THROUGH SPINDLE......................... 2.08"
RANGE OF SPINDLE SPEEDS (INF VARIABLE)....... 4 - 4000 RPM
RAPID TRAVERSE (Z)........................... 393.70 IPM
RAPID TRAVERSE (X)........................... 393.70 IPM
TAILSOCK QUILL TRAVEL........................ 4.72"
QUILL DIAMETER............................... 2.36"
QUILL TAPER HOLE............................. 4MT
MAIN MOTOR................................... 12.5 HP
APPROXIMATE FLOOR SPACE ..................... 122" x 50"
APPROXIMATE WEIGHT .......................... 5,500 LBS
- SIEMENS 802D CONTROL w/MANUAL GUIDANCE SOFTWARE, TOOL
PATH& 3D PART SHAPE GRAPHICS, TEACH MODE, CONVERSATIONAL
PROGRAMMING, G CODE PROGRAMMING, BUILT-IN DRO
- 10 HP VARIABLE SPEED SPINDLE DRIVE
- TURN PARTS MANUALLY OR AUTOMATICALLY
- DUAL ELECTRONIC HANDWHEEL CONTROLS
- "TEACH" 1ST PART, RUN REMAINING PARTS AUTOMATICALLY
- USB PORT<, FLASH MEMORY CARD SLOT & RS 232 PORT
- 10.4" COLOR LCD DISPLAY
- 8" 3-JAW CHUCK
- RIGID TAPPING
- CONSTANT SURFACE SPEED
- INCH/METRIC CONVERSION
- MULTI-START THREADING, THREAD REPAIR
- DORIAN MODEL: CXA QUICK CHANGE TOOLPOST
- BORING BAR HOLDER
- COOLANT SYSTEM
- AUTOMATIC LUBRICATION SYSTEM
This equipment has been sold. Similar equipment available now is shown below.
